COS 426 Assignment 6

Ray Tracing

Your program will support two primitives: spheres and triangles. You'll have a simple material model and a handful of lights. In order to get complete credit, a number of possible extensions and their various point values are specified below.

Your program will take its input in a simple ASCII format (which, conveniently, is parsable by Tcl) and will generate its output as PPM "raw" image files (click here for the PPM specification).

Advice

Ray tracers are very, very modular programs. If you start early, you can design a system where you can add features as you go. You may want to seriously consider using an object-oriented programming style (either in C or C++).

Ray tracers can be extremely small programs, too. Check out Paul Heckbert's ray tracer on the back of a business card.

Ray tracers generate really beautiful pictures. Check out The Raytracing Competition for some inspiration.

Scenes

A number of sample scenes will eventually be available in the cs426 class directory. Stay tuned.

Camera

camera_from   x y z

Location of the camera in world coordinates.

camera_target x y z

The camera is looking at this point in space. You may prefer to use camera_forw.

camera_forw   x y z

The vector defines which direction is forward.

camera_up     x y z

The vector defines which direction is up.

camera_angle  theta

The angle, in degrees, specifies the angle from the left side of the screen to the right side of the screen. When you're rendering your image, you'll use this number to space out the rays you fire. You should scale this angle appropriately in the Y direction based on the resolution of the output image. If the image is wider than tall, the angle from top to bottom will be proportionately smaller.

camera_resolution x y

The pixel resolution of the final output image.

Geometry

max_vertices n

Hint to the system that you'll have no more than this many vertices - makes memory allocation simpler. This statement should occur before any vertices are specified.

max_normals  n

Hint to the system that you'll have no more than this many normals - makes memory allocation simpler. This statement should occur before any normals are specified.

vertex  x y z

Each time you run this command, you add a vertex to the vertex pool. Future references to these vertices will be by vertex number. The initial vertex is number zero.

normal  x y z

Just like vertex, this command adds a normal to the normal pool, with numbering that begins at zero. The normal pool should be kept separate from the vertex pool.

You may find it useful for the vertex and normal commands to return their index numbers back to Tcl.

tri     v1 v2 v3

This adds a triangle to the world using these three vertices. This triangle is flat, and its normal vector can be inferred from the vertices. In case you decide you care, you can treat these vertices as occuring in counter-clockwise order (i.e.: if you want to do backface culling - this isn't required, though).

ntri    v1 n1 v2 n2 v3 n3

This is just like the tri primitive except you get to specify a normal for each vertex. Remember, the normals come from the normal pool and the vertices come from the vertex pool.

Note: the arguments passed to tri and ntri are indices into the vertex and normal pools.

sphere  x y z radius

This adds a sphere to the world centered at the given point with the given radius.

Lights and Materials

background       r g b

Defines the background color, i.e., when a ray doesn't intersect anything in the scene. Note that R,G,B are defines as floating point numbers between zero and one.

ambient_light    r g b

Defines an ambient light - all objects are illuminated by this light. Note: the world can have precisely one ambient light. Further calls to ambient_light redefine this number.

parallel_light   r g b   x y z

Defines a parallel light - much like the sun, these lights are infinitely far away, and only have a direction vector.

point_light      r g b   x y z

Defines a point light - these radiate light evenly in all directions, but their energy falls off as 1/r².

spot_light       r g b   px py pz  nx ny nz  angle1 angle2

Defines a spot light - this is optional for your assignment. Spot lights exist at a point in space (px,py,pz) and point in a given direction (nx,ny,nz). angle1 and angle2, both in degrees, specify how the light falls off. For any angle between zero and angle1, the light should be just like a point light. Between angle1 and angle2, the light falls off. For angles greater than angle2, the light isn't there. If you do this, start with linear falloff, then you may want to play with various gamma functions (just like assignment 2).

material  r g b  Ka Kd Ks n_s  T index_of_refraction

RGB is in terms of 0.0 to 1.0.

Ka is the ambient component, Kd is the diffuse component, Ks the specular, n_s is the Phong cosine power for highlights, T is transmittance (fraction of contribution of the transmitting ray). Usually, 0 <= Ka <= 1, 0 <= Kd <= 1, and 0 <= Ks <= 1, though it is not required that Ka + Kd + Ks == 1. Note that transmitting objects (T > 0) are considered to have two sides for algorithms that need these (normally objects have one side). Also note that you can use Ks to define the contribution of a reflected ray.

The fill color is used to color the objects following it until a new color is assigned.

For the assignment, you're required to deal with neither transparent nor reflective objects. It's optional. See the Grading section, below.

Miscellaney

render file.ppm

Given the full scene, camera, lighting, and such has been specified, this runs the ray tracer and sends its output to "file.ppm" in PPM "raw" format. It should only take you about six lines of code to do this: just use fputc() for the R, G, and B parts and fprintf() for the headers.

You should be able to view your images with xv, where you can convert them to any other format, such as GIF and JPEG for your personal Web pages.

clear_scene

Frees all internal memory. If you want to write a Tcl script that generates multiple images, you'll need this.

trace_depth n

It's possible for your raytracer to get into infinite loops, so this specifies the maximum number of bounces before you terminate a ray.

Implementation Notes

Pay very careful attention to this quote:

Novice programmers often neglect the design phase, instead diving into coding without giving thought to the evolution of a piece of software over time. The result is a haphazard, poorly modularized code which is difficult to maintain and modify. A few minutes of planning short-term and long-term goals at the beginning is time well spent.

- Paul Heckbert, ``Writing a Ray Tracer,'' in An Introduction to Ray Tracing, edited by Andrew Glassner.

Assuming you implement your ray tracer using Tcl as an interface, you'll only need Tcl, not Tk. A side benefit is that you can run your program anywhere, not just an SGI. Ultimately, you should have a Tcl script which runs your ray tracer like so:

raytrace teapot.tsd teapot.ppm

#!./rayshell

source [lindex $argv 0]
render [lindex $argv 1]
exit

Grading

Note: you may want to think about continuing your ray tracer for your final project.

In the process of implementing some of the extensions, you'll want to add new commands to the Tcl script to handle them. Please take the time to argue about them in the pu.cs.426 newsgroup so people may actually standardize on some of these extensions and be able to share input files.

Finally, also submit a URL (in your README) of your favourite image, created with your ray tracer. Maybe you can make it to look like this... (image created by Kevin Odhner).
